Quick Details

  • Place of Origin: Zhejiang, China (Mainland)
  • Brand Name: YYOPTO
  • Model Number: HLSP60-250M
  • Material: Monocrystalline Silicon
  • Size: 1650*992*40mm
  • Number of Cells: 60
  • Max. Power: 270
  • nominal voltage: 30.7v
  • voltage open circuit: 38.1V
  • Cell Efficiency: 17.46%
  • short-circuit current: 8.97A
  • 250w solar panel Weight: 19.5KG
  • Power tolerance: 0 to +3%
  • 250w solar panel Dimension: 1640x992x40mm
  • Maximum voltage: 1000v

Packaging & Delivery

Packaging Details pallet+carton+wooden or we can packing as your request
Delivery Time 7 days after Deposit received.

2015 Hot sales low price buy nano solar panels/solar module

Product Description

1.Watt Rating: 250w

2.Dimensions: 1650x990x50 mm

3.Quicker installation means quicker returns.

4.This 60-cells module was specially designed by YYOPTO for large rooftop and open space systems.

5.Through the use of efficient polycrystalline cells, this panel provides an achieved performance efficiency of up to 17%.

6.In a large project, this cellular module can help you save cost in labor and installation.





1. Monocrystalline solar panel ELELTRICAL CHARACTERISTICS:
Model     HLSP60-220MHLSP60-230MHLSP60-240MHLSP60-250M
Cellmonomonomonomono
Pmax(Power)*220W230w240w250w
Vmp(nominal voltage). V29.2v29.7v30.2v30.7v
Voc(voltage open circuit). V36.2V36.8V37.4V38.1V
Isc(short-circuit current). A8.11A8.30A8.58A8.97A
Cell Efficiency15.06%15.75%16.43%17.46%
Maximum voltage. V1000
Power tolerance0 to +3%
* 2.NOCT:45Deg
Operating temperature -45/+80Deg
*STC:Irradiation 1000 W/M2,AM 1.5,Temoerature 25Deg
Temperature coefficients of Voc (%)   -(2.23+/-0.1)mv/ °C
Temperature coefficients of Isc (%) 0.065+/-0.015%/ °C
Temperature coefficients of Pm (%   -(0.5+/-0.05)%/ °C
Temperature coefficients of Im (%)   +0.1/ °C
Temperature coefficients of Vm (%)   -0.38/ °C
Junction boxCIXI/IP65/6(manufacturer / protection degree / number of diodes)
Front coverTempered Glass, 4.0mm (material / thickness [mm])
Cell Type (technology /quantity / )60pcs / 156x156mm / polycrystalline
Encapsulation materials Ethylene Vinyl AcetateEVA
Rear cover (material / thickness [mm])Le – PET – PVDF / 0.287
FrameAnodised aluminium profile
Max. wind load / Max. snow load [Pa]2.4K/5.4 K
Length of Cables/connector 900mm
 * 3.PHYSICAL CHARACTERISTICS:
Weight19.5KG
Dimension(LxHxD) in mm1650x992x50
This panel is made up of 60pcs 156x156mm monocrystalline cells.
40'HQ could load:532 pics  (2pcs per carton)







Packaging & Shipping

250w mono solar panel packing: pallet+carton+wooden or we can packing as your request.

250w mono solar panel shipping:7 days after order.









Our Services
1.Modern Management with a professional and efficient team.
2.All workers pass the skills access before working.
3.Using the newest technology and equipment, 90% of the production facilities are imported from Germany and Italy.
4.Products are approved by TUV,CE.
5.Powerful Research Ability, 15~20 new kinds of products are launched each year.
6.Annual 200MW solar panel and solar cell production capacity.
7.80% of our products are exported to more than 60 countries in the world.
8.Successful projects were installed in more than 60 countries in the world.





Company Information

1. YYOPTO is an international PV supplier manufacturer in China from 2004.

2. YYOPTO has the Modern Management Method.

3. YYOPTO has a professional and efficient team, and all workers pass the skills access before work.

4. YYOPTO uses the newest technology and equipment, 90% of the production facilities are imported from Germany, Italy and US.

5. All products are approved by ISO9001/14001, TUV, UL, CE& CSA.

6. YYOPTO has annual 200MW solar panel and solar cell production capacity.

7. 80% of our products are export to more than 60 countries in the world. Successful projects were installed in more than 60 countries in the world





FAQ

1. Q: Are you a factory or trading company?

A: We are a factory.

2. Q: Where is your factory located? How can I visit there?

A: Our factory is located in Jinhua , Zhejiang, China, near Shanghai. You are warmly welcomed to visit us!

3. Q: How can I get some samples?

A: Please connect me for samples, and my phone number: +86 15907191067.

4. Q: Can the price be cheaper?

A: Of course, you will be offered a good discount for big amount.
